  • Description: FHS2T Series Optical Laser Source is an advanced version of FHS2 Series of Optical Laser Sources, with one more wavelength for FTTX PON testing. Auto-wavelength Recognition: FHS2T Series Optical Laser Source transmits with a wavelength-identification digital encrypted protocol, enabling FHP2 Series Optical Power Meter to automatically use the proper calibration wavelength. This feature reduces the need for communication between the two technicians and decreases the possibility of making mistakes. FHS2T Series Optical Laser Source offers excellent stability and portability for accurate fiber optic testing. Single output port provides stable laser power at three wavelengths. The compact unit operates in either continuous wave (CW) mode or modulated mode. A low battery indicator reminds the user of replacing the battery. Testing Range: Maximum testing range up to 150km (when using Grandway’s FHS2T Series Optical Laser Source with Granway’s FHP2A04 Optical Power Meter). Features: Easy-to-use, straight forward operation Eye-catching handheld appearance LCD backlight for easy operation in dark environment ±3dB adjustable output Rechargeable battery inside 1310 & 1490 & 1550nm available for PON testing Four wavelengths available for multi-purpose testing One-year warranty and recommended calibration interval
  • Description: FHS2Q Series Optical Laser Source is an advanced version of FHS2 Series of Optical Laser Sources, with two more calibrated wavelengths. Auto-wavelength Recognition: FHS2Q Series Optical Laser Source transmits with a wavelength-identification digital encrypted protocol, enabling FHP2 Series Optical Power Meter to automatically use the proper calibration wavelength. This feature reduces the need for communication between the two technicians and decreases the possibility of making mistakes. FHS2Q Series Optical Laser Source offers excellent stability and portability for accurate fiber optic testing. Two output ports provide stable laser power at four wavelengths. The compact unit operates in either continuous wave (CW) mode or modulated mode. A low battery indicator reminds the user of replacing the battery. Features: Easy-to-use, straight forward operation Eye-catching handheld appearance LCD backlight for easy operation in dark environment Rechargeable battery inside Four wavelengths available for multi-purpose testing One-year warranty and recommended calibration interval
  • První „tablet“ Last-Mile OTDR MAX-715B . Je optimalizovaný pro point-to-point testování a odstraňování problémů FTTx architektury a je ideální pro testování krátkých vláken (např. uvnitř CO nebo FTTA/DAS) nebo metropolitních sítí do vzdálenosti 60km.
  • Description: Grandway provides high precision optical power meter. FHP1 Series Optical Power Meter is designed for use with an Optical Laser Source for performing optical loss measurements on fiber optic cables. FHP1 Series Optical Power Meter is designed for low budget. It can meet the basic demand in real testing. With the smaller size and light weight, it is easier to take in real testing. Features: 1.Integrated with high performance optical detector 2.Medium size, light weight, and great portability 3.Lower power consumption 4.Easy to use 5.Integrated with auto-power-off, low power indication and measurement interchanging functions 6.Internal charging circuit, back light 7.Lower cost
  • Description: FCA-10 CWDM Analyzer is specially designed for CWDM installation, maintenance and troubleshooting, which is able to measure and monitor power values of 10 CWDM channels. FCA-10 CWDM Analyzer can replace high-cost Spectrometers and conduct quick and reliable measurements in all environments. Thanks for its light, compact and sturdy design, FCA-10 CWDM Analyzer is an ideal tool for CWDM installation and maintenance. Features: 1.Hand-held, more compact and easy to operate 2.TFT LCD display 3.10 CH wavelength testing: 1431nm~1611nm 4.Histogram or list data display modes 5.Can work as the normal power meter 6.Inner timing system 7.Threshold configuration: can preset threshold value 8.Data Transfer to PC via USB 9.Backlight function 10.10 hours continuous work 11.Data storage & download
  • Description: FHS2 Series Optical Laser Source is an advanced version of Laser Sources, with better features and more functions. Auto-wavelength Recognition: FHS2 Series Optical Laser Source transmits with a wavelength-identification digital encrypted protocol, enabling FHP2 Series Optical Power Meter to automatically use the proper calibration wavelength. This feature reduces the need for communication between the two technicians and decreases the possibility of making mistakes. FHS2 Series Optical Laser Source offers excellent stability and portability for accurate fiber optic testing. Single output port provides stable laser power at dual wavelengths. The compact unit operates in either continuous wave (CW) mode or modulated mode. A low battery indicator reminds the user of replacing the battery. Features: Easy-to-use, straight forward operation Eye-catching handheld appearance LCD backlight for easy operation in dark environment ±3dB adjustable output Rechargeable battery inside 850 & 1300nm available for multimode testing One-year warranty and recommended calibration interval
  • Description: FHS1 Series Optical Laser Source offers excellent stability and portability for accurate fiber optic testing. Single output port provides stable laser power at dual wavelengths. The compact unit operates in either continuous wave (CW) mode or modulated mode. A low battery indicator reminds the user of replacing the battery. Features: Both single mode and multiple mode laser are available Single output interface Rugged and portable Auto power-off function Integrated with continuous wave output function, 270Hz, 1kHz and 2kHz are available
  • Description: FMP-10 MPO Power Meter & FMS-10 MPO Laser Source are high cost performance testers to test MPO connectors and patchcords and display all the test results Intuitively on the TFT LCD. They can perform polarity test and frequency identification. Features: Test all the fibers in MPO connector Polarity test Display all the optical power on the screen Recognize 270Hz, 1000Hz and 2000Hz frequencies Application: Data center MPO patchcord manufacturing Research organization and laboratory
  • Description: FHP12 Series Mini Optical Power Meter has compact structure and stable performance and ensures high measuring precision of 850nm, 1300nnm, 1310nm, 1490nm, 1550nm and 1625nm wavelengths. Used together with Optical Laser Source, it could accurately measure the loss of bier, cable and other passive optical devices. Feature: Imported sensor head 2.5mm universal interface (support FC/SC/ST connectors) Low power consumption, continuous work more than 100 hours Linear optical power and logarithmic power display Automatic measuring range adjust and power remains indication Relative value measurement Compact and portable design
  • Description: As the industry\'s advanced PON-specific power meter, FHP3P01 PON Power Meter is the flagship of Grandway’s line of testing instruments specifically intended for FTTH and FTTP systems. It is the ideal tool for FTTH/FTTP service activation and troubleshooting. Service Activation Testing: Optimizing network reliability requires that all PON signals be measured all the way through service activation to ensure they meet established standards. FHP3P01 offers the features to address this need: Pass-through connection for ONT signal measurement and simultaneous measurement of all PON signals. Filtered detectors for individual measurement of each wavelength. Upstream burst detection at 1310nm. Troubleshooting Testing: Throughout the maintenance phase, various transmission problems, like fiber cuts, damaged/dirty connectors, macro bending, optical transmitter failure, etc. may ultimately cause signal loss or degradation. Benefit from FHP3P01 troubleshooting functionalities: Quick, on-site test and measurement of PON signals, anywhere on the network. Fault identification and isolation. Features: Hand-held and battery operated FTF LCD Display with high resolution Filtered measurements with distinct power display Simultaneous measurement and display power lever of 1310,1490,1550nm WL Pass/fail function available. Up to10 user defined threshold Ability to upgrade software through USB interface 1000 sets data storage Software to generate Test Report
  • Description: FHP2P01 PON Optical Power Meter is a small size, low loss and good quality handed-held meter. It is designed for the testing, installation and maintenance of FTTX PON network, which can be used for APON, BPON, EPON and GPON network. FHP2P01 PON Optical Power Meter has two output ports for ONU and OLT/Video, which supports CW/burst upstream detection at 1310nm and downstream signal at 1490/1550nm. It can directly show the status of pass, warning or failure by threshold testing. FHP2P01 is an ideal tool for PON installation and maintenance. Feature: 1.Handed-held, easy-to-carry and use 2.P/F testing and normal testing mode 3.Two testing ports with “ONU” & “OLT/Video” 4.Support 1310nm upstream CW/burst signal and 1490nm/1550nm downstream signal 5.Design for networks of APON, BPON, EPON and GPON 6.Threshold programmable 7.Huge data storage capability 8.Software is available for communication
  • Description: FHP2 Series Optical Power Meter is the advanced version of OPM series. It is more functional and intelligent. Under the situation of laboratory, LANs, WANs and CATV as well as long distance optical network, Optical Power Meters, together with Grandway\'s Stabilized Optical Laser Sources, can be used to identify optical fiber, measure optical attenuation, verify continuity an evaluate fiber link transmission quality. Auto-wavelengths Recognition: FHS2D02 Optical Laser Source can transmit with a wavelength identification digital encrypted protocol, enabling FHP2 Series Optical Power Meter to automatically switch to the proper calibration wavelength. This feature reduces the need for communication between the two technicians and decreases the possibility of making mistakes. Referencing Function: Signal encrypting can also give the receiving end information on the power to be used as reference, helping ensure efficient referencing, even when the two units are far apart. Computer Supported: Memory capacity of 1,000 data items; enables data transfer to a PC via USB connection. With the software, the datasheet can be saved as excel or txt, and print out directly. Testing Range: Maximum testing range up to 150km (when using Grandway’s FHS2D02 Optical Laser Source with Grandway’s FHP2A04 Optical Power Meter). Feature: 1.Integrated with high performance optical detector 2.LCD backlight for easy operation in darker environments 3. Two powering systems: internal rechargeable batteries or AC adaptor 4.Wide dynamic range and high power measurement capability 5.High accuracy and stabilized 6.Auto-off function: saves the power and low power consumption allows extended operation in the field 7.Recommended calibration interval
